PostPosted: Mon Feb 07, 2011 5:53 pm
Offline
Koa
Koa

Joined: Fri Mar 31, 2006 4:54 pm
Posts: 707
Location: United States
First name: nick
Last Name: fullerton
City: Vallejo
State: ca
Zip/Postal Code: 94590
Country: usa
Focus: Build
Status: Amateur
I have an pretty stupid question to ask about my newly acquired Ibex fret rule. It has a mark for bridge compensation that reads distance to E string. Now is that the high or low E string? I've been searching all over for instructions but can't find any.

duh

_________________
"Preoccupation with an effect gives it power and enhances the error"
from "Your Owner's Manual" by Burt Hotchkiss.


Top
 Profile

PostPosted: Mon Feb 07, 2011 6:16 pm
Offline
Koa
Koa
User avatar

Joined: Fri Feb 01, 2008 8:47 am
Posts: 1223
Location: Montreal, Canada
Focus: Build
Status: Professional
Hi Nick,

I got an Ibex fret rule as well and even though the saddle postion specifies the E string (which should be the high E by the way), I found the intonation to be better when I position saddle mark right in the middle of the saddle.

My 2 cents...

EDIT: By the way, my Ibex fret rule is an old one that is not available anymore (at least not from Stewmac), where 4 different scalelength were shown. So maybe we are not talking about the same fret rule...

_________________
Alain Moisan
Acoustics, Classicals and Flamencos.
www.guitaresmoisan.com
Facebook


Top
 Profile

PostPosted: Mon Feb 07, 2011 6:37 pm
Offline
Koa
Koa

Joined: Thu Sep 10, 2009 4:01 pm
Posts: 1462
Location: UK
Might just be a good idea to check the accuracy of that fret rule. I too have an old model, but it's way off - at least when I compare it to a high quality metre rule.
It's a long time since I used it for marking fret positions, for obvious reasons. I spent a whole day making my own version out of wood, complete with 4 scale lengths. Not only is it more accurate but I cut very fine and shallow saw cuts for the markings. You don't have to eyeball it, simply engage a marking knife into the fine slot.

_________________
www.historicalguitars.co.uk


Top
 Profile

PostPosted: Mon Feb 07, 2011 7:28 pm
Offline
Cocobolo
Cocobolo

Joined: Thu Dec 16, 2010 2:57 pm
Posts: 133
First name: Tom
Last Name: Dl
Country: Canada
Focus: Build
Status: Amateur
I have one of those and it gets used for some basic stuff like maybe sizing up a piece of wood. I use templates for standard fare, and I use w-fret for custom sizes.


Top
 Profile

PostPosted: Tue Feb 08, 2011 1:39 am
Offline
Koa
Koa

Joined: Fri Mar 31, 2006 4:54 pm
Posts: 707
Location: United States
First name: nick
Last Name: fullerton
City: Vallejo
State: ca
Zip/Postal Code: 94590
Country: usa
Focus: Build
Status: Amateur
Thanks for the replies. I got this ruler from Martin's website, deciding to give it a try because it was affordable. I finally glued the bridge today and am pretty sure I got it right going to the low E string (much to my surprise). I'll let you know tomorrow if I did it wrong. I used the Cumpiano/Natelson book as guide in cutting my slot, and since the center measurement from fret twelve equalled the nut to twelve, I figured this must be the way. (hope that made sense)...

_________________
"Preoccupation with an effect gives it power and enhances the error"
from "Your Owner's Manual" by Burt Hotchkiss.


Top
 Profile

PostPosted: Tue Feb 08, 2011 9:40 am
Offline
Koa
Koa
User avatar

Joined: Fri Feb 01, 2008 8:47 am
Posts: 1223
Location: Montreal, Canada
Focus: Build
Status: Professional
nickton wrote:
... and since the center measurement from fret twelve equalled the nut to twelve, I figured this must be the way.


Well, if I understand your statement correctly, it won't be right. The distance between the nut to the 12th fret should be slightly shorter than the distance from the 12th to the saddle (a little from the high E, a little more from the low E). What you will end up with is a saddle that is not compensated, therefore your guitar will sound sharper and sharper as you move up the fretboard.

_________________
Alain Moisan
Acoustics, Classicals and Flamencos.
www.guitaresmoisan.com
Facebook


Top
 Profile

PostPosted: Tue Feb 15, 2011 5:37 pm
Offline
Koa
Koa

Joined: Fri Mar 31, 2006 4:54 pm
Posts: 707
Location: United States
First name: nick
Last Name: fullerton
City: Vallejo
State: ca
Zip/Postal Code: 94590
Country: usa
Focus: Build
Status: Amateur
Yep. Don't know what I was on that time, but I had to re-set my bridge, after checking it with my other guitar. oops_sign duh

I eventually want to get some of those stewmac scale rules, and maybe learn how to figure out any scale length but for now I'm keeping it simple.


You do not have the required permissions to view the files attached to this post.

_________________
"Preoccupation with an effect gives it power and enhances the error"
from "Your Owner's Manual" by Burt Hotchkiss.


Top
 Profile

PostPosted: Tue Feb 15, 2011 8:09 pm
Offline
Contributing Member
Contributing Member
User avatar

Joined: Mon Mar 19, 2007 7:05 am
Posts: 8710
Location: United States
First name: Waddy
Last Name: Thomson
City: Charlotte
State: NC
Focus: Build
Status: Semi-pro
I have one of the old IBEX rules, and the "standard classical scale" is some wierd scale that is more than 650, and the compensation is too much for the scale, but it works fine. I used it on my first few, and it came out just fine. Intonation was perfectly good. That's a classical. Don't know about the other scales.

_________________
Waddy

Waddy Thomson Guitars

Waddy's Guitar Build Albums 16 done - 2 in process.

Sound Clip from #1: Barrios' "Una Limosna por el Amor de Dios" (An Alm for the Love of God) -Not me playing! I could never.....!


Top
 Profile

PostPosted: Wed Feb 16, 2011 2:23 am
Offline
Koa
Koa

Joined: Fri Mar 31, 2006 4:54 pm
Posts: 707
Location: United States
First name: nick
Last Name: fullerton
City: Vallejo
State: ca
Zip/Postal Code: 94590
Country: usa
Focus: Build
Status: Amateur
I just checked out your build pictures and am quite amazed Waddy. I have a loooong way to go.

_________________
"Preoccupation with an effect gives it power and enhances the error"
from "Your Owner's Manual" by Burt Hotchkiss.


Top
 Profile

PostPosted: Wed Feb 16, 2011 10:22 am
Offline
Contributing Member
Contributing Member
User avatar

Joined: Mon Mar 19, 2007 7:05 am
Posts: 8710
Location: United States
First name: Waddy
Last Name: Thomson
City: Charlotte
State: NC
Focus: Build
Status: Semi-pro
Thanks, Nick. I have build threads over at LuthierCom.org for all but the first. There is a bit more discussion along with the same pictures. The first is archived here in multiple posts.

_________________
Waddy

Waddy Thomson Guitars

Waddy's Guitar Build Albums 16 done - 2 in process.

Sound Clip from #1: Barrios' "Una Limosna por el Amor de Dios" (An Alm for the Love of God) -Not me playing! I could never.....!
